Ball Screws With Interchangeable Nut-Shaft Combinations

NSK is releasing a new series of ball screws in which the nut and shaft can be freely combined. This design makes it easier for both dealers and end users to stock or purchase high quality ball screws in small batches.

The new ball screw does not require using an individually matched nut-shaft combination. Instead, the nut and shaft can be freely interchanged, following the principle of random matching.

Available in accuracy class C7, the ball screws come in shaft diameters from 15 to 32 mm, with pitches from 5 to 20 mm. Thanks to their inherent design, the units are shipped with very little axial play as standard. If necessary, a desired preload can be generated by changing the size of the balls at a NSK dealer or directly at NSK.

The new series is ideal for applications that include pick-and-place systems, as well as automated transfer units for assembly, handling and internal transport. Many other uses are also possible.

For users, the free interchange of nut and shaft has the advantage that the required ball screw can simply be taken or ordered from stock, and then cut to length either in-house or by an authorised NSK dealer.

About NSK Europe

NSK Europe Ltd. is the European organisation of the Tokyo-based bearing manufacturer NSK, which was founded in Japan in 1916 and today employs around 31,000 people in its worldwide operations. The products and solutions provided by the industrial and automotive supplier can be found wherever things move. In addition to nearly all types of rolling bearings, the company’s portfolio includes housed bearings, linear technology, wheel bearing units, transmission and engine bearings and steering systems. The company is oriented to perfection in all of its business activities. Its aim is quality leadership in its industry, which it strives for through a continuous process of improvement, excellent product development, optimised production processes and customer-oriented service processes.

www.nskeurope.com

In a new series of ball screws, the nut and shaft are designed according to principle of random matching
